Messerschmitt Me P.1092/5

         This final design of the Messerschmitt Me P.1092 series was another refinement of the previous, Me P.1092/4 design. The cockpit was again moved, this time back to its original location (from the first Me P.1092A design) above the wings. Again, the wing and tail were taken from the Me 262, and the air intake and jet engine remained from the previous P.1092 designs. Armament consisted of four MK 108 30mm cannon, located on the fuselage sides.
          The Me P.1092 series of designs went no further than the drawing board. However, the design work and performance calculations  formed the basis of the later Me P.1106 and even the Me P.1101 projects.


Messerschmitt Me P.1092/5 Dimensions
  Span      Length      Height      Wing Area      Aspect Ratio
9.4 m
30' 9"
8.1 m
26' 6"
3.6 m
11' 9"
12.7 m²
136 ft²
7.0:1
The Messerschmitt Me P.1092/5 weights and performances should be comparable to the Me P.1092/2


Messerschmitt Me P.1092/5 Models
There are no scale models currently of any of these aircraft








Above color image from: Geheimprojekte der Luftwaffe: Jagdflugzeuge
